V-NOTCH BALL VALVE SERIES 3002
The V–Notch Ball Valve gives non-clogging, high capacity, straight through flow control of fluids containing pulp and paper stock or slurries and fluids containing suspended solids or fibrous materials.
Design Features
- A Shearing effect between the ball and seal ensures tight shut-off, even on fibrous slurries.
- The unrestricted, straight – through flow design provides high capacity and wide rangeability.
- Precise contouring of the V-notch balls provides a nearly equal percentage characteristic.
- Replaceable ball seal and back up ring for added rigidity.
- Ball machined to a super smooth finish, hard – chrome plated and polished to increase Ball seal life.
- High Cv to body size ratio.
Get a Custom Solution Quote
Tell us your requirements. Our engineers will design it for you.
- Quick Response within 24 Hours
- Engineered to Meet Your Exact Specifications
Technical Specification
| Design | BS. 5351 |
| Series | 310 – 2 Piece Design 370 – 1 Piece Design |
| Size | 15 to 300 mm (1/2” to 12”) |
| Rating | ANSI 150 |
| End Connection | Flanged End |
| F/F Dimensions | ANSI B-16.10 |
| Flow Characteristics | Modified Equal Percentage, Linear, On-Off |
| Flow Direction | Forward (into convex face of V-ball) |
| Max. Ball Rotation | 90° |
| Body Material | Carbon Steel, Stainless Steel, Alloy Steel, etc. |
| Ball Material | CF8M Chrome Plated / Alloy Steels |
| Seat | Soft / Metal Seat |
| Ball Ring | CF8M, Alloy Steels |
| Gasket | PTFE, Graphite Laminate |
| Gland Packing | PTFE V Rings, Grafoil |
| Actuator Form | Diaphragm, Rotary, Electric |
| Air Connection | 1/4” or 1/2” NPT |
| Accessories |
Valve Positioner – Pneumatic, Electro Pneumatic, Smart Positioner Instruments – Airset, Solenoid Valve, Air Lock, Volume Booster, Position Transmitter, Limit Proximity Switches, etc. Features: Top or Side Mounted Handwheel, Limit Stops |
